Additional Information
Key Features
- Epson’s First UV Flatbed Signage Printer A groundbreaking addition to the signage market, designed specifically for printing on rigid substrates with exceptional quality.
- Wide Media Compatibility Supports a wide variety of applications for substrates of up to 80mm thick, expanding your service offerings significantly.
- 10-Color UltraChrome UV Ink Delivers striking prints with smooth gradation, vivid reds, and a wide color gamut suitable for high-end retail and décor.
- GREENGUARD Gold Certified Meets strict chemical emissions limits, making it safe for use in sensitive indoor environments like schools and hospitals.
- PrecisionCore Technology Utilizes Epson’s patented PrecisionCore printheads for impressive color consistency and high-speed production.
- User-Friendly Operation Features an intuitive operating system designed to improve productivity, safety, and overall usability.
Technical Specifications
Printing Technology
| Printer Type | UV Flatbed Large Format Printer |
|---|---|
| Printing Technology | PrecisionCore TFP (Thin Film Piezo) |
| Nozzle Configuration | 800 Nozzles x 10 Colors (8,000 Nozzles Total) |
| Maximum Print Resolution | 1,440 x 1,440 dpi |
| Ink Type | UltraChrome UV Ink (10 Colors) Colors: Cyan, Magenta, Yellow, Black, Light Cyan, Light Magenta, Light Black, Orange, Green, White |
Media Handling
| Max Media Thickness | Up to 80mm |
|---|---|
| Printable Area (Flatbed) | Up to 2,500 x 1,250 mm (Approx. 8' x 4') |
| Compatible Media | Acrylic, PVC, Foam Board, Wood, Metal, Glass, Cardboard, and other rigid substrates. |
Performance
| Print Speed (Draft Mode) | Approx. 14.8 m²/h (160 sq ft/h) |
|---|---|
| Print Speed (Production) | Approx. 8.4 m²/h (90 sq ft/h) |
| Accuracy | +/- 0.3% or less |
Dimensions & Weight
| Product Dimensions (W x D x H) | 3,828mm x 2,397mm x 1,358mm (With Legs) |
|---|---|
| Product Weight | Approx. 870 kg (Without Inks) |
| Control Panel | 4.3 inch Color LCD Touchscreen |
Power & Electrical
| Rated Voltage | AC 200 - 240V |
|---|---|
| Frequency | 50 / 60 Hz |
| Power Consumption (Operating) | Approx. 3.5 kW |
| Power Consumption (Sleep) | Approx. 4.0W |
Operational Environment Standards
| Operating Temperature | 10°C to 35°C (Recommended: 15°C to 30°C) |
|---|---|
| Operating Humidity | 20% to 80% (No condensation) |
| Safety Certifications | GREENGUARD Gold Certified, UL, CE |
| Interface | USB 3.0, 1000BASE-T Ethernet |
