Additional Information
The Advantage: Inorganic Ink Technology
The T1320-10 doesn't just print; it preserves. By utilizing specialized inorganic inks, it offers performance that far surpasses traditional organic alternatives.
1. Built to Last (Excellent Durability)
- Unwavering Light Resistance: Defies UV radiation. Your colors stay vibrant and true, even after years of exposure to direct sunlight.
- All-Weather Toughness: Designed to withstand nature's worst. From heavy rain and wind to fluctuating temperatures, your prints won't powder or peel.
- Extreme Heat Resistance: While organic materials might decompose under high heat, our inorganic inks can withstand extreme temperatures without losing integrity.
2. Superior Chemical Stability
Quality that stands the test of time. Our ink is highly resistant to acids, bases, and solvents. This prevents unwanted chemical reactions that cause discoloration, ensuring your patterns stay sharp and clear for years.
Product Specifications
General Parameters
| Product Name | T1320-10 Ceramic Printer |
|---|---|
| Brand | HTX |
| Place of Origin | Henan, China |
| Warranty | 1 Year |
| Certification | CE Certified |
| Inkjet Technology | Piezoelectric Inkjet with Grayscale Printing |
| Print Resolution | 1200 dpi |
| Color Configuration | CMYK (Optional 6-color scheme) |
| Ink Type | Special Inorganic Inks |
| Operating System | Windows 7 / 10 |
Performance & Capacity
| Print Heads (Optional) | Seiko RC1536 / Dimatix SG1024 / Xaar 2002 |
|---|---|
| Head Configuration | 4 / 8 / 12 Heads (Optional up to 18) |
| Max Print Speed | 0.7 m/s |
| Max Print Width | 1.3m – 3m |
| Capacity (2 Pass) |
4 Heads: 30-50 ㎡/h 8 Heads: 60-100 ㎡/h 12 Heads: 90-150 ㎡/h |
Media & Mechanical Specs
| Compatible Media | Flexible Stone, PU Stone, Ceramic Tile, Glass, Metal |
|---|---|
| Media Thickness | 3mm – 50mm (Variable thickness supported) |
| Media Flatness Requirement | ≤ 2mm |
| Machine Dimensions (L×W×H) | 4700mm × 2900mm × 2000mm |
| Weight | Approx. 3000kg |
Operational Environment
| Power Supply | 380V |
|---|---|
| Max Power | 20kW |
| Ambient Temperature | 20℃ – 30℃ |
| Relative Humidity | 35% – 65% |
Application Scope
Ideally suited for architectural decoration materials:
Flexible Stone
Printing realistic stone textures on bendable substrates for interior and exterior wall cladding.
PU Stone
High-definition patterns for polyurethane stone panels, offering a lightweight yet durable finish.
Hard Materials
Compatible with Ceramic Tiles, Glass, and Metal plates for customized industrial decoration.
