Additional Information
Why Choose the T2150-10?
Discover a printer built for the future of stone decoration.
- Engineered for Industry The T2150-10 is built tough for heavy-duty industrial use. It handles large-scale projects effortlessly with a maximum media width of 1.3m–3m.
- No High-Energy Firing Say goodbye to expensive, energy-intensive kilns. Our printer cures at low temperatures (30–38℃), cutting your energy costs significantly while maintaining top-tier quality.
- Photo-Realistic Detail Bring your designs to life with stunning 1200 dpi resolution. Our grayscale printing technology captures every nuance, delivering textures so realistic they look and feel like the real thing.
- Speed That Scales With You Whether you are a startup or a large factory, we have a configuration for you. Choose from 4, 8, 12, or 18 print heads to match your desired production speed—from 30㎡/h up to a rapid 150㎡/h.
- Smart & Automated Focus on production, not maintenance. Equipped with an intelligent ink shortage alarm and ICC color control curves, the T2150-10 ensures consistent quality with minimal manual intervention.
The Advantage: Inorganic Ink Technology
The T2150-10 doesn't just print; it preserves. By utilizing specialized inorganic inks, it offers performance that far surpasses traditional organic alternatives.
1. Built to Last (Excellent Durability)
- Unwavering Light Resistance: Defies UV radiation. Your colors stay vibrant and true, even after years of exposure to direct sunlight.
- All-Weather Toughness: Designed to withstand nature's worst. From heavy rain and wind to fluctuating temperatures, your prints won't powder or peel.
- Extreme Heat Resistance: While organic materials might decompose under high heat, our inorganic inks can withstand extreme temperatures without losing integrity.
2. Superior Chemical Stability
Quality that stands the test of time. Our ink is highly resistant to acids, bases, and solvents. This prevents unwanted chemical reactions that cause discoloration, ensuring your patterns stay sharp and clear for years.
Product Specifications
General Parameters
| Product Name | T2150-10 Ceramic Printer |
|---|---|
| Certification | CE Certified |
| Inkjet Technology | Piezoelectric Inkjet with Grayscale Printing |
| Print Resolution | 1200 dpi |
| Color Configuration | CMYK (Optional 6-color scheme) |
| Ink Type | Special Inorganic Inks |
| Operating System | Windows 7 / 10 |
Performance & Capacity
| Print Heads (Optional) | Seiko RC1536 / Dimatix SG1024 / Xaar 2002 |
|---|---|
| Head Configuration | 4 / 8 / 12 Heads (Optional up to 18) |
| Max Print Speed | 0.7 m/s |
| Max Print Width | 1.3m – 3m |
| Capacity (2 Pass) |
4 Heads: 30-50 ㎡/h 8 Heads: 60-100 ㎡/h 12 Heads: 90-150 ㎡/h |
Media & Mechanical Specs
| Compatible Media | Flexible Stone, PU Stone, Ceramic Tile, Glass, Metal |
|---|---|
| Media Thickness | 3mm – 50mm (Variable thickness supported) |
| Media Flatness Requirement | ≤ 2mm |
| Machine Dimensions (L×W×H) | 4700mm × 2900mm × 2000mm |
| Weight | Approx. 3000kg |
Operational Environment
| Power Supply | 380V |
|---|---|
| Max Power | 20kW |
| Ambient Temperature | 20℃ – 30℃ |
| Relative Humidity | 35% – 65% |
Application Scope
Ideally suited for architectural decoration materials:
Flexible Stone
Printing realistic stone textures on bendable substrates for interior and exterior wall cladding.
PU Stone
High-definition patterns for polyurethane stone panels, offering a lightweight yet durable finish.
Hard Materials
Compatible with Ceramic Tiles, Glass, and Metal plates for customized industrial decoration.
