Additional Information
Series Highlights
- Piezo Electric Technology Utilizes on-demand piezo electric technology for precise ink jetting and long operational life.
- High Nozzle Count Features 512 nozzles per head with a native resolution of 360 dpi, ensuring consistent coverage and high-speed output.
- Versatile Ink Compatibility Engineered to work with Oil Based, Solvent, and UV inks, providing flexibility for various industrial applications.
- Temperature Control Options Select models (LH, MH) feature integrated heaters (up to 55°C) for optimal ink viscosity management.
- Greyscale Capability Models like the MN and MH support 4-level greyscale mode, enabling variable drop sizes for superior photo quality.
Technical Specifications by Model
Model KM512 MN (Also known as KM512 MNX)
A greyscale capable head offering variable drop sizes for higher print quality.
| Technology | On-Demand Piezo Electric |
|---|---|
| Native Resolution | 360 dpi |
| Cal. Droplet Size | 14 pico litre |
| Greyscale | Yes (4 level, Max 3 drops) |
| Tot. Amount of Nozzles | 512 (256 nozzles per line) |
| Nozzle Spacing | 70.5 microns |
| Print Width | 36.1 mm |
| Firing Frequency | 12.8 kHz |
| Ink Compatibility | Oil Based, Solvent, UV Inks |
| Heater | Not integrated |
Model KM512 LN (Also known as KM512 LNX)
Designed for binary mode printing with a larger droplet size for dense coverage.
| Technology | On-Demand Piezo Electric |
|---|---|
| Native Resolution | 360 dpi |
| Cal. Droplet Size | 42 pico litre |
| Mode | Binary Only |
| Tot. Amount of Nozzles | 512 (256 nozzles per line) |
| Nozzle Spacing | 70.5 microns |
| Print Width | 36.1 mm |
| Firing Frequency | 7.6 kHz |
| Ink Compatibility | Oil Based, Solvent, UV Inks |
| Heater | Not integrated |
Model KM512 LNX-35
A binary mode head optimized for solvent inks with a mid-range droplet size.
| Technology | On-Demand Piezo Electric |
|---|---|
| Native Resolution | 360 dpi |
| Cal. Droplet Size | 35 pico litre |
| Mode | Binary Only |
| Tot. Amount of Nozzles | 512 (256 nozzles per line) |
| Nozzle Spacing | 70.5 microns |
| Print Width | 36.1 mm |
| Firing Frequency | 10 kHz |
| Ink Compatibility | Solvent |
| Heater | Not integrated |
Model KM512 LH (Also known as KM512 LHX)
Features an integrated heater, ideal for temperature-sensitive UV and oil-based inks.
| Technology | On-Demand Piezo Electric |
|---|---|
| Native Resolution | 360 dpi |
| Cal. Droplet Size | 42 pico litre |
| Mode | Binary Only |
| Tot. Amount of Nozzles | 512 (256 nozzles per line) |
| Nozzle Spacing | 70.5 microns |
| Print Width | 36.1 mm |
| Firing Frequency | 7.6 kHz |
| Ink Compatibility | Oil Based, Solvent, UV Inks |
| Heater | Integrated (Up to 55°C) |
Model KM512 MH (Also known as KM512 MHX)
The premium greyscale model with integrated heating for maximum versatility.
| Technology | On-Demand Piezo Electric |
|---|---|
| Native Resolution | 360 dpi |
| Cal. Droplet Size | 14 pico litre |
| Greyscale | Yes (4 level, Max 3 drops) |
| Tot. Amount of Nozzles | 512 (256 nozzles per line) |
| Nozzle Spacing | 70.5 microns |
| Print Width | 36.1 mm |
| Firing Frequency | 12.8 kHz |
| Ink Compatibility | Oil Based, Solvent, UV Inks |
| Heater | Integrated (Up to 55°C) |
Printer Compatibility
The Konica Minolta KM512 series is widely supported across the industrial printing industry. Compatible printers include:
- Agfa Anapurna M
- Agfa Anapurna M4f
- Agfa Anapurna Mv
- Agfa Anapurna Mw
- Allwin C8
- Anhui Liyu Maxima PZ3204-KM
- Anhui Liyu Maxima PZ3206-KM
- Canon Océ CS6060
- Canon Océ CS6100
- DGI OrionJet OR-1806
- DGI SaturnJet ST-1806
- Dilli Neo Titan UVT-1606S
- Dilli Neo Titan UVT-1606W
- DYSS Apollo PTP18/3202-KC
- DYSS Apollo PTP3204-KM
- Flora HJ 3200 Turbo
- HP Designjet 10000s
- HP Designjet 9000s
- Icontek 3306
- JHF Vista H8 3304FN
- Myjet LB3208KM42
- Oki ColorPainter 100S
- Oki ColorPainter 64S
- Rodin K4320-A
- Skynet HS-Series
- Sun Innovations Neo Da Vinci
- Taimes T5
- Taimes T7
